Time：2020-04-23 11:47:26
Seawater Desalination Plant for the Sea-line Resort - Qatar customers Model: 8m3/hr Seawater Desalination Plant I. Seawater Desalination Plant background: In 2018/10 we got an inquiry from an engineer in Qatar and their company is engaged in marine works and construction, they are commissioned to construct a sea-line resort in Qatar. For the Seawater Desalination Plant, the product water will be used for Hotel and Resort, and they prefer design the plant operate for 8-10 hours/day. After further discussing about the requirements, we offered the quote. The engineer is satisfied with the quote, but they will make the decision in December as they have many other aspects quotes need time to be evaluated. Then in 2018/12, we contacted with the engineer for further issues discussion, so they finally decide to cooperate with us. Thus we received the deposit in 2019/01, we finished the system in 2019/03. After receiving the left payment in 2019/03, we arranged the shipping in 2019/04 and the client picked up the system in 2019/04. Then for the installation of the system, our technicians offer online supports for solving some installation and layout questions. In 2019/06 the system finally be well-installed and well-operated. The engineer said that their managements are happy for our product quality and our after-sales service, for following seawater desalination projects they would like to cooperate with us in the future. II. Seawater Desalination Plant Design basis: 1. Feed water: Seawater, set TDS=35000ppm 2. Product water: Drinking directly 3. Water temperature: 2—50℃ 4. Production capacity: 8.0m³/hr 5. Voltage: 415V, 50Hz, 3 phase 6. Power supply: 60kw/hr 7. Delivery: 40ft High Cubic Container×1 III. Seawater Desalination Plant Process flow: IV. Seawater Desalination Plant Technical details: Name Specification Quantity Raw water tank Material: PE/SUS/RC Capacity: 25m3 1 set Feed water pump Model: ZS65-50-200 Q=22m3/h H=36m Material: SUS316L Power: 7.5KW Brand: CNP/CHINA 1 set Accessories Base,regulating valve, check valve, etc. 1 lot Sand filter vessel Model:Φ1500×2400(mm) Material: FRP Brand: HY/CHINA 1 set Quartz sands Application: Get rid of turbidity, suspended matter, organic matters, colloid ,etc. Brand: HY/CHINA 3000 kg Control valve Model: F112B Apply: AUTO Brand: RUNXIN/ CHINA 1 set Scale inhibition Metering pump: KCL-635 Brand: SEKO/ITALY 1 set Medicine tank Material: PE Volume: 100L Brand: HY/CHINA 1 piece Security filter 5µ housing Material: FRP Brand: HY/CHINA 1 set Security filter element Model: 80"×40" Rating level: 5µ Brand: HY/CHINA 1 piece Security filter 1µ housing Material: FRP Brand: HY/CHINA 1 set Security filter element Model: 80"×40" Rating level: 1µ Brand: HY/CHINA 1 piece High pressure pump Model: MA2260 Q=21.1m3/h H=57.5m Material: SUS316L Power: 45KW Brand: PINFL/GERMANY 1 set Accessories Base,regulating valve, check valve, etc. 1 lot Secondary high pressure pump Model: CDM10-17 Q=10m3/h H=153m Material: SUS304 Power: 7.5KW Brand: CNP/CHINA 1 set Accessories Base,regulating valve, check valve, etc. 1 lot RO Membrane Model: SW8040HR-400 Specification: 8040 Material: Aromatic poly-amide Desalination rate: 99.8% (single) Arrange order: 3×6 Brand: VONTRON/CHINA 18 piece RO Membrane housing Material: FRP Specifications: 8040 × 6 (1000PSI) Brand: HY/CHINA 3 piece Secondary RO Membrane Model: LP22-8040 Specification: 8040 Material: Aromatic poly-amide Desalination rate: 99.5% (single) Arrange order: 1×6 Brand: VONTRON/CHINA 6 piece Secondary RO Membrane housing Material: FRP Specifications: 8040 × 6 (300PSI) Brand: HY/CHINA 1 piece Accessories Valves, flow meters, pressure gauges, etc. 1 lot Chemical cleaning device (Pump) Model: ZS65-40-125 Material: SUS316L Power: 3.0KW Brand:CNP/CHINA 1 set Chemical cleaning device (Security filter) Material: FRP Brand: HY/CHINA 1 set Chemical cleaning device (Security filter element) Model: PP 40" Brand: HY/CHINA 1 piece Chemical cleaning device (Water tank) Material: PE Volume: 1000L Brand: HY/CHINA 1 piece Frame Material: Carbon steel Rustproofing Brand: HY/CHINA 1 set Full-auto Application: AC contractor, time relay, insurance etc electrical components, electric cabinet, Wire and cable. Brand: China famous brand 1 unit Pipes Low pressure pipeline Materia : UPVC Brand: HY/CHINA 1 lot High pressure pipeline Material: SUS316 Brand: HY/CHINA 1 lot RO water tank Material: PE/SUS/RC Capacity: 10m3 1 set Output water tank Material: PE/SUS/RC Capacity: 8m3 1 set V. Why choose Haiyuan: Take 'Customer first, Integrity-based' as our core value, our company has offered hundreds of clients high-quality products with professional guidance and satisfied after-sale service.Hence, we are capable to show you our products range and guide you to choose the system best fit your needs. We will provide high-quality, all-round comprehensive professional services for project consulting, system design, manufacturing, installation and commissioning, personnel training, etc. VI. More inquiries regarding Seawater Desalination Plant: Whatsapp me or call me via +86 13544774483 Email : sales010@water-sy.com
Electrical controller system
