HYWATER BWRO | SWRO Desalination | Water Maker
RO sea water desalination plant for boat |Sea water desalination plant|Sea water desalination 50 m³/hr for boat A.RO sea water desalination plant for boat design basis Raw water : seawater with TDS 41000 ppm Production capacity:50m³/h Product water : for human domestic water Voltage and frequency: 3PH 400V/60HZ,184KW B.Sea water desalination plant control method Whole system use full automatically control model, both model can be exchanged accordingly. Sand filter with auto and manual back flush.The RO system automatic flushing at each start-up and shutdown. High water level auto stop, low water level auto start.Pump protected without water.Protected when no power, poor power, larger electrical current, leakage, short circuit. C.Sea water desalination process Sea water tank →Feed water pump →Sand filter → Scale inhibition→ 5μSecurity filter →1μSecurity filter → High-pressure pump → SWRO with CIP→ fresh water tank RO sea water desalination plant for boat stage introduction S.N Item Application 1 Raw water tank Store water, buffering pressure, overcome instability of supplying water by pipe, ensure to supply water stably and continuously for whole system 2 Raw water pump Provide needed pressure for every filtrator. 3 Multimedia filter We use filber-glass or stainless steel vessel as housing, fill quarts sand and anthracite, it can filter big particles impurities, suspended substances, colloids etc. 4 5μm Security filter/cartridge filter Prevent large particles, bacteria, viruses into RO membrane, accuracy 5μm 5 1μm Security filter/cartridge filter Prevent large particles, bacteria, viruses into RO membrane, accuracy 1μm 6 High pressure pump Provide needed working pressure for RO system, ensure production capacity of pure water. 7 RO system Can remove particles, colloids, organic impurities, heavy metal ions, bacteria, virus, heat source ect. Harmful substances and 99% dissolved salts. D. RO sea water desalination plant for boat configuration table 1 Model JISHUI-SWRO-50 m³/hr 2 Core filtration component USA DOW brand 4040 seawanter desalination membrance 8pcs 3 Preteatment Quartz sand filter ,5micron PP filter and 1 micron pleated PP filter 4 Raw water pump Lingxiao pump,2.2kw 5 High-pressure pump Italy water inlet AR high pressure pump , 11kw,380v ,3phrase 6 Instrument Raw water pump inlet water pressure, gauge ,high-pressure pump inlet water pressure gauge ,fresh water flowmeter. 7 Online conductivity meter korida online conductivity meter 8 Ootional Configuration UV sterilizer,liquid level switch ,pressure tank carbon filter E.Sea water desalination plant trade term Price term: FOB (from Shenzhen,China ) Payment term: 30% deposit advanced, 70% balance payment before delivery. Package size: 2*40 HQ Assembly time: 8 weeks (from the date of receipt of payment) Warranty Period: 1 year Why need to provide the source water quality report? 1.The source water quality report can help engineers better understand the parameters of various indicators n the raw water, like the amount of all kinds of ions, bacteria, etc. Provide feasibility solution based on various parameter of raw water. 2. TDS(Total dissolved solid) and residual chlorine value is very import. before designing the proposal, engineers select high different pressure pumps with different pressures based on TDS value to make sure that the system can produce the clean water normally. Select the appropriate stainless steel material based on the residual chlorine to avoid the water leakage caused by corrosion. 3.From water analysis report can see the iron and manganese, turbidity, bacteria whether exceed the standard. Engineers can design the process flow chart and solution which best fit the demand to help reduce unnecessary expense which can help customers save the cost. 4. Engineers design the RO sea water desalination plant for boatsuitable proposal based on raw water quality report and product water purpose/standard which can operate normally and best fit the customer demand. BTW: If source water is Municipal tap water or clean reservoir water or spring water no need report. But please inform us the water characteristic. Email: Sales@seawaterroplants.com Mob&WeChat&WhatsApp: +8613544774483/ +8613922972795 More inquiries related to RO sea water desalination plant for boat |Sea water desalination plant|Sea water desalination(different source water, capacity, voltage), please feel free to contact us! Email: Sales@seawaterroplants.com Mob&WeChat&WhatsApp: +8613544774483/ +8613922972795 We will provide high-quality, all-round comprehensive professional services for project consulting, system design, manufacturing, installation and commissioning, personnel training, etc. Portable mobile desalination plant 1TPD
